How Are Flight Plans Filed?

How Are Flight Plans Filed?

BY EMMETT CHUNG 19870d AGO 0 COMMENTS

When a flight is scheduled anywhere around the world, it requires a plan to be filed either with international authorities or the local jurisdiction. In this short article, we will briefly examine the process of filing flight plans for domestic flights in the United States.



FAA regulations require flight plans for most commercial flights mostly for the purpose of safety. Federal officials verify fuel calculations to make sure the plane can actually reach its destination and also notify air traffic controllers to minimize the risk of a midair collision.

In addition, flight plans have a standardized format worldwide under the ICAO (International Civil Aviation Organization), an agency of the United Nations.



A Vietnam Airlines Boeing 787-10 takes off from SFO.  It filed a flight plan for a flight from San Francisco to Anchorage, credit: J.V. Mehta | AeroXplorer



Flight planning requires millions of calculations that usually are performed by computers. Previously, this process was done by hand but computers are obviously much more efficient. They calculate the fastest route possible and/or that with the best fuel efficiency. In certain cases, however, a plane is required to fly along a specific predetermined path known as an airway or air route, for example, while flying over the ocean far from the coast.



The route produced by flight plans day after day may seem similar, but in fact takes into account a number of extremely variable factors which include (but are not limited to) weather, altitude, extra fuel for emergencies, weight of the aircraft, and more.



Of course, computers do not handle all of the work of flight planning. Obviously pilots must follow the plan but they are aided by airline dispatchers (also known as flight dispatchers or operations officers) who, within a certain geographic area, monitor conditions and relay (hence the name) new information to pilots. Computers are not perfect, so the role of the dispatcher is crucial in the event of, for example, inclement weather. In addition, dispatchers handle much of cancellations, diversions, and emergency landings. Dispatching is a stressful task: not only do planners have to monitor 10-25 flights at once with varying degrees of concentration, but under federal law a dispatcher is 50% responsible for the safety of all flights they monitor (the pilot having the rest of the responsibility).



TAP Air Portugal's Airbus A330neo lifts off from San Francisco, credit: J.V. Mehta | AeroXplorer



Most flight plans have an aircraft flying on an airway, an invisible pathway in the sky defined by named waypoints. Air traffic control is responsible for guiding the pilot along an airway. In certain cases where following the airway would be less efficient, direct waypoint to waypoint routing is possible, abbreviated as DCT.



Waypoints are updated and released every four weeks by the country under whose jurisdiction they fall. When taking off and landing, standardized flight procedures exist linking a waypoint to a runway. This primarily exists to maximize airport efficiency.



That was a lot, no? Here's an example from a transcontinental flight that demonstrates waypoints in action.



United Airlines Flight 2418 (UA2418)

Sunday, August 30, 2020

San Francisco (SFO) to Newark (EWR)

Boeing 777-200

Planned Speed: 557 mph

Planned Altitude: 37,000 ft

Planned Distance: 2,573 mi



Route Points

4 letters = Airport

5 letters = Waypoint

3 letters = VOR-TAC (Radio beacon)



KSFO - San Francisco Intl. Airport (Origin)

TYDYE - San Francisco Bay

TRUKN - Oakland Intl. Airport - Alameda County, CA

COSMC - Alameda County, CA

TIPRE - San Joaquin County, CA

INSLO - Nye County, NV

DTA - Millard County, UT

LBF - Lincoln County, NE

OBH - Greeley County, NE

DSM - Warren County, IA

EVOTE - Branch County, MI

NELLS - Monroe County, MI

KEEHO - Lake Erie

DORET - Clermont County, OH

ZORBO - Warren County, PA

SLT - Potter County, PA

FQM - Lycoming County, PA

MEGSS - Luzerne County, PA

HAYED - Luzerne County, PA

RACKI - Carbon County, PA

PENNS - Northampton County, PA

SWEET - Warren County, NJ

KEWR - Newark Liberty Intl. Airport (Destination)



Route (Map courtesy of FlightAware)
